LONCIN LC3500i User Manual

Chapter IV Disassembly & Repair
- 42 -
99
4-5-3 Rack baseplates
Disassembly/assembly
REASSEMBLY:
After reassembly, check the
operation of the float.
FUEL METER
REASSEMBLY:
Make sure the passages are
not clogged.
Check for fuel leakage after
installation.
FUEL VALVE
REASSEMBLY:
Wash to remove sediment and
dry thoroughly before
installation.
SEDIMENT CUP
Cushion seat of
main engine (2)
Assembly:
Ensure the rubber is not cracked,
hardened or worn. And note the
assembly direction.
Nut M8 (8)
Torque: (8~12) N•m
Clip nut M5 (4)
Square nut M6 (6)
Torque: (8~12) N•m
Brake
Cushion rubber
Rack baseplates
Vertical framework (2)
Cushion seat of
main engine (2)
Support of handle of pull rope
Guide pad of brake
Parts of
supporting wheel (4)
Dust cover of
supporting wheel (4)
Gasket (4)
Protective cap of brake
Lock disk of wheel shaft
Vertical framework (2)
