CHAPTER III MACHINE OPERATION
51
Figure 21 SHOVEL EARTH
2 、 Taking back and lifting the bucket.
3 、 Keep the bucket 300mm from the ground during the transportation.(as shown in the figure 22)
Figure 22 TRANSPORTATION
4
、
Arrived at the designated location, rising boom, dumping, all operations are stable.
