LORCH V27 - Pc-board DK-DCI40; DK-ACI40; Functions; Picture pc-board DK-DCI40; DK-ACI40

page 10
Pc-board DK-DCI40 / DK-ACI40
The pc-board DK-DCI40 (DC machines) and DK-ACI40 (AC machines) is the front panel with all buttons and opti-
cal displays.
Functions
- operating and handling of the machine
- display of operational parameters and error messages
Picture pc-board DK-DCI40 / DK-ACI40
buttons and LEDs only
mounted at pc-board
DK-ACI40
X1
