page 27
Pc-board DK-HFDC / DK-HFDC HV
The pc-board DK-HFDC is the ignition device of the welding machine.
In the machines V40 and V50 the pc-board DK-HFDC HV is used. All other machines are equipped with the pc-
board DK-HFDC.
Functions
- generating high voltage pulses
Picture pc-board DK-HFDC
Overview connections pc-board DK-HFDC
connector designation
X1 interface to pc-board DK-MAPRO
X3 connector for HF-inductor
