2. Ifdishwasherisinstalledatthecornerofthecabinet,thereshouldbesomespace
whenthedoorisopened.
Dishwasher
Doorof
dishwasher
Cabinet
Minimumspaceof50mm
NOTE:
Dependingonwhereyourelectricaloutletis,youmayneedtocutaholeinthe
oppositecabinetside.
Step 2. Aesthetic panel‘s dimensions and installation
The aesthetic wooden panel could be processed according to the installation
drawings.
Semi-integrated model
MagicalpasterAandmagicalpasterBbedisjoinedon,magicalpasterAonthe
aestheticwoodenpanelandfeltedmagicalpasterBoftheouterdoorofdishwasher
(seegureA).Afterpositioningofthepanel,xthepanelontotheouterdoorby
screwsandbolts(SeegureB).
A
B
Magical
paster
Magical
paster
1.Takeawaythefourshortscrews
2.Pinupthefourlongscrews
