9.5 Liquid Level Sensor
The LORENTZ range of liquid level sensors use pressure to
measure the level or water in a well or tank. The sensors
can be used for long term water level monitoring and also
for pump control in applications where a well probe cannot
be used.
For further information about the Level sensor please refer
to the COMPASS datasheet.
9.6 Pressure Sensor
The LORENTZ range of liquid pressure sensors are used to
measure the pressure in a pipe. The sensors are commonly
used to measure the pressure at a well head or feeding into
irrigation systems.
For more information about the pressure sensor please refer
to the COMPASS datasheet. Ensure that the pressure sensor
is suitable for your application regarding pressure range and
temperature resistance.
Figure 25: LORENTZ Liquid Level Sensor Figure 26: LORENTZ Pressure Sensor
60 Pump Accessories Installation
Pump Accessories Installation 61
