9
Figure 3:
P
osition of holes for fixation for PS150,
PS200
Figure 5:
Steel conduit threads for PS150,
PS200
Figure 4:
P
osition of holes for fixation for PS600,
PS1200,
PS1800
Figure 6:
Steel conduit threads for PS600,
PS1200, PS1800
250 mm
395 mm
371 mm
35 mm
12 mm
206 mm
146 mm
M4
M4
M4
M4
190 mm
156 mm
116 mm
8
×
M8
116 mm
156 mm
177 mm
Ø
47 mm
M50
Pg 36
Ø
29 mm
M25/M32
Pg 21
Ø
23 mm
M20/M25
Pg 16
Ø 19
M20
Pg 11
Ø
29 mm
M25/M32
Pg 21
Ø
29 mm
M25/M32
Pg 21
8
10
Table of Contents
Default Chapter
2
Table of Contents
2
1 Introduction
4
2 Warnings
4
3 Installing the Solar Array
6
Location of the Solar Array
6
Solar Array Assembly Methods
6
Solar Array Mounting Rack
6
Orienting the Solar Array to Solar South
6
Figure 1: Suncompass
6
Setting the Solar Array Tilt Angle
7
4 Electrical Installation
8
Controller, Junction Box and Conduit
8
Figure 2: Transportation Protection Caps and Boots
8
Figure 3: Position of Holes for Fixation for PS150, PS200
9
Figure 5: Steel Conduit Threads for PS150, PS200
9
Figure 4: Position of Holes for Fixation for PS600, PS1200, PS1800
9
Figure 6: Steel Conduit Threads for PS600, PS1200, PS1800
9
Figure 8: Conduit Holes
10
Grounding and Lightning Protection
11
Solar Array Wiring
12
Figure 9: Two Types of PV Module Junction Systems
12
Solar Array Disconnect Switch in the Junction Box
13
Junction Box (Controller Input) Wiring
13
Figure 10: Controller Terminals
13
Maximum RPM Setting
14
Submersible Pump Cable and Splice
14
Figure 11: Terminals Inside the PS Controller
14
Figure 12: Cable Splice
14
Wiring the Pump
15
Wiring Order for Correct Rotation
15
Low-Water Probe for Dry-Run Protection
16
Figure 13: Low-Water Probe Installed in the Standard Position, for a Pump that Is Po
16
Automatic Control for Full-Tank Shutoff
17
Figure 14: Float Switch Scheme
17
Figure 15: Wiring a "Normally Open Float Switch
17
Figure 16: Wiring a "Normally Closed/Reverse Action Float Switch
17
Battery-Based Systems
19
Pressurizing Systems
20
Figure 17: Wiring for Pressure Switch
20
Figure 18: Typical Assembly for Automatic Water Pressurising
20
5 Preparing to Install the Pump
21
Warnings for Handling Helical Rotor Pumps
21
Assembling the Rotor on the Motor Shaft
21
Figure 19: Assembling the Rotor on the Motor Shaft
21
Drop Pipe
22
Figure 20: Hose Clamp to Reinforce a Plastic Reducer Bushing
22
Safety Rope and Binding
23
Figure 21: Safety Rope
23
6 In-Well Assembly and Installation
24
Installation in a Surface Water Source
24
Deep Well Setting - How Deep
24
Installation
24
Figure 22: Minimum Angle When Positioning the Pump in an Inclined Position
24
Coping with Dirty Water Conditions
25
Utilizing a Low-Production Water Source
25
Figure 23: Stilling Tube for HR Pumps
25
