Connecting the Camera
3
NVR over a single CAT5E cable. In order to use PoE with this IP camera, you
must connect it directly to a compatible NVR or a PoE switch on the same net-
work as the NVR.
NOTE
• For the most up-to-date list of compatible recorders, please visit
www.lorextechnology.com/compatibility
• PoE switches are available for purchase on www.lorextechnology.com.
Complete the following steps to connect the camera to the NVR over the LAN.
Step 1 of 2 — OPTION A: Connecting the camera to your local network
using an optional PoE switch:
1. Connect an Ethernet cable of up to 300ft (91m) rated CAT5e or higher
(not included) from the LAN port on an external PoE switch (sold sepa-
rately on www.lorextechnology.com) to your router. Connect the power ca-
ble to the PoE switch and plug into a power outlet or surge protector.
NOTE
Terminology may vary depending on the model of PoE switch you have.
#LX400075; r.41474/41994; en-US
