Controlling the PTZ camera with LNR / NR Series NVRs
6
PTZ Controls
1. Direction keys: Click to pan and tilt the camera. Click SIT to stop the cur-
rent action.
2. PTZ Trace: Click to activate mouse PTZ Trace mode. You can do the
following:
• Click and drag to move the camera.
• Use the scroll wheel to zoom in and out.
• Right-click to exit and return to normal PTZ controls.
3. Zoom/Focus/Iris: Click +/- to adjust the zoom, focus, and iris. Adjusting
the camera’s iris settings allow you to control the amount of light that en-
ters the camera’s lens. The higher the iris value, the greater the amount of
light that enters the camera’s lens.
CAUTION
Adjust the camera’s iris settings to match the environment where the camera is in-
stalled. Too much light exposure might result in a very bright camera image.
4. Advanced controls: Click to open advanced PTZ controls.
5. Speed: Enter a PTZ speed between 1 (slowest) and 8 (fastest).
6.2 Advanced PTZ Controls
Advanced PTZ controls can be used to save camera positions and cycle
through various positions, and automate camera actions.
To open advanced PTZ controls:
• Click the arrow in the PTZ control window to open advanced controls.
#LX400075; r.41474/41994; en-US
18
