Technical Specifications
8
Image Sensor 1/2.7", CMOS 2.1 MP
Video Format
NTSC / PAL
Effective Pixels 1928 (H) x 1088 (V)
Resolution Up to 1080p
Range 0°～355° Pan; 0°～90° Tilt
Pan/Tilt Speed Manual Speed — Max 80°/Sec Pan; Max 40°/Sec Tilt
Preset Speed — Max 100°/Sec Pan; Max 60°/Sec
Tilt
Tour Speed — Max 80°/sec Pan; Max 40°/Sec Tilt
Zoom 4x Optical Zoom & 16x Digital Zoom
Scan System
Progressive
Synchronization
Internal
S / N Ratio
≥50dB
Iris Auto Iris
Min. Illumination
0.1 Lux in Color; 0.05 Lux in Black and White
Lens / Lens Type 2.7mm ~ 11mm ,F1.6 ~ F2.7 / Auto / Manual Focus
Field of View (Horizontal) 95°～30°
Day/Night IR Cut Filter (ICR)
Termination RJ45 10 M / 100M Ethernet
Video Output RJ45
Power Requirement PoE (Power over Ethernet, Class 2); 12V DC
(Optional)
Power Consumption Max. 500mA
Operating Temperature Range -22°F ~ 140°F / -30°C ~ 60°C
Operating Humidity Range
<95%RH
Indoor/Outdoor Both (IP66)
1
Weight (Camera Alone)
Weight (Camera & Wall Mount)
1.20lbs / 0.54kg
2.35lbs / 1.06kg
#LX400075; r.41474/41994; en-US
27
1. Not intended for submersion in water. Installation in a sheltered location recommended.
