Adjust the Operator’s Console
The Articulating Arm supporting the operator’s console is pre adjusted at the factory. However, if it
needs to be adjusted during nal assembly, all the adjustment wrenches are included in spare parts
/ tool kit, which is included with roaster.
Take care with articulating arm, so as not damage the console or the roaster. Incidental damage is
not covered by warranty The following diagrams so how to carry out adjustments to the Articulating
Arm.
1
2
3
4
