Major Components, Assembled
The core pieces of Loring coffee-roasting equipment are the coffee roaster itself and a Green Bean
Cart that is included with the S15 roaster. A separate piece of optional equipment, the Destoner, is
described in a separate manual.
Green Bean Hopper (Auto Hopper System)
Roaster Body
Cooling Tray
Cyclone
Front Left View
Back Right View
Front Right View
S-Duct
Auto Hopper Blower
Operator Console and Electrical Enclosure
Chaff Barrel
Mini Cyclone
1
3
4
5
6
7
8
1
1
1
2
2
3
3
3
4
4
4
5
5
5
6
6
7
8
9
9
Front
2
2
8
