Loring Falcon S15 - Back View, Components, As Shipped

S15 Assembly and Installation Guide
1008286 Rev B
Loring Smart Roast Proprietary – This document is controlled by
Document Control. By printing this document, it will become a “Reference” copy.
Users are responsible for verifying that it is the latest revision available.
Page 9 of 50
Some roaster components are more easily visible prior to equipment assembly – mainly, various
fans and motors. These components may be referenced during assembly instructions.
Back View, Components, As Shipped
11
Circulation Fan
Drum Drive Motor
Cooler Fan Motor
Cooler Fan Motor Housing
Auto Hopper Blower
(From previous page)
(Current image)
Operator Console
Utility Tray
Air, Gas, and Water Hookups
11
12
14
6
7
15
16
16
17
18
18
14
13
15
6
17
2
3
7
Back Left View
Cooling Tray
3
Back
Roaster Body
2
