S15 Assembly and Installation Guide
1008286 Rev B
Loring Smart Roast Proprietary – This document is controlled by
Document Control. By printing this document, it will become a “Reference” copy.
Users are responsible for verifying that it is the latest revision available.
Page 45 of 50
Hot Air Exhaust Vent Connection
Front
Front
Back
Back
6" (15 cm)
Minimum inside diameter
Refer to the Pre-Installation
and Site Preparation Guide
for additional system
specications and operating
temperatures.
Stack
To Next Page
