5.11 MOIsTuRE ON/Off
Using the moisture sensor is an optional
feature of the Elite Yield Monitor. Toggle the
sensor On or O here if for example you are
adding a moisture sensor at a later point.
6.0 comBine SeTup
e Combine Setup screen is used to dene the Make & Model
of your combine as well as Header Switch/Sensor, Speed Source,
and Grain Loss settings.
6.1 MAkE
From the popup select the appropriate make
of your combine (John Deere, Case, Gleaner,
New Holland, Massey, Claus, or Other).
6.2 MODEL
Depending on the combine make, the subsequent combine
models are grouped by similar combine models. In most cases
your combine model will be listed, if not select the nearest model
shown or select “Other” for the Combine Make.
6.3 HEADER sWITCH/sENsOR
Selecting this option will load a popup for
selecting both the type and dening the up
and down position of the header switch. Select
the “Type” button in the upper le corner to toggle between a
“Switch” and a “Sensor” type cutout.
6.3.1 HEADER puLL sWITCH
Select this option when using a pull-chain style cutout switch.
Lower the header to cut height and select “Set Lowest” to
correctly orient the sensor for this crop.
6.3.2 vARIAbLE HEIgHT sENsOR
Select this option when using a variable header height sensor.
Raise the header to its highest position and select “Set Highest”.
en lower header to its lowest position and select “Set Lowest”.
is denes the maximum and minimum voltage range of the
sensor as well as the direction of change between up and down
positions.
6.4 spEED sOuRCE
Used to select what method the Elite Yield
Monitor is receiving speed, select between
GPS Receiver, Sha Sensor, or Simulated
Speed.
6.4.1 gps RECEIvER
Used with either an existing GPS receiver
or one supplied by Loup Electronics. is
option must also be enabled when logging
any eld maps. See Section 7.0 to congure the GPS Receiver.
6.4.2 sHAfT spEED
If you’re using a sha speed sensor and
no eld maps are being logged, select this
option.
