Cable connections.
Note: External speaker wires in power/data cable not shown.
Mounting the Unit: Bracket or In-Dash
You can install the unit on the top of a dash with the supplied gimbal
bracket. It can also be installed in the dash or mounted on a portable
power supply.
If you use the supplied bracket, you may be interested in the optional
R-A-M
bracket mounting system. This converts the unit's gimbal
bracket to a swivel mount, which can be used on the dash or overhead
mounting positions. Installation instructions are supplied with the
R-A-M mounting kits.
Sonar unit,
rear view
GPS
antenna
module
GPS socket
Power/Data socket
Power wires
(two)
Com port
data wires
(three)
Sonar socket
Transducer
