Setting up
CG-6 Operation Manual p/n 115370001 Rev A
Figure 3-7 The level window size editing screen
Note: The level window size is the threshold under which the leveling
arrows will appear as green. For instance, if the threshold is set to 20 arseconds, then
once the tilt of one of the axes is within ± 20 arcseconds, then the leveling arrow for this
axis will appear green.
The level window size can be set (in arcseconds) to any value between 5 and 200. To
enter the window size value, move the cursor to the chosen character and press the
Enter button. To clear the entire field, move the cursor to the CLEAR field and press the
Enter button. To clear the last character that was entered, move the cursor to the
Backspace field and press the Enter button. Once you are satisfied with the value of
your window size, move the cursor to the ACCEPT field and press the Enter button. To
exit this screen, move the cursor to CANCEL and press the Enter button.
To exit this screen, move the cursor to CANCEL and press the Enter button.
Adjusting the auto contrast of your screen
The automatic adjustment of the contrast of your screen can be set to ON or OFF. The
auto contrast function should generally be left on at all times. The contrast will
automatically be adjusted based on the lcd screen temperature. This is convenient when
you are operating in field conditions, where the amount of sunshine can vary throughout
the day. To adjust the auto contrast, move the cursor to Auto Contrast and press the
Enter button. The following screen will appear:
