4 -23
(10) Recommended maximum specification of implements
No. Implements Specification
J2023H
1 Front loader
Max lift capacity
(Bucket pivot point)
509 kg (1122 lb)
2 Rotavator Max tilling width 1219 mm (48 in)
3 Backhoe Max digging depth 1954 mm (77 in)
4 Rotary cutter Max working width 1372 mm (54 in)
5 Mid mower Max working width 1524 mm (60 in)
6 Landscape lake Max working width 1219 mm (48 in)
7 Box blade Max working width 1219 mm (48 in)
8 Rear blade Max working width 1372 mm (54 in)
z When attaching implements to the tractor, refer to the followings recommended as maximum
specification of each implement. DO NOT attach bigger implements then this specification. For other
implements, contact your authorized dealer.
