5 -15
▶ When engine oil is warm, the
impurities can be drained
completely.
Notice
① Drain Engine oil
z Run engine for a few minutes to warm oil.
z Park the tractor on a level surface.
z Remove drain plug of oil pan and drain the oil
completely.
5-7. Every 300 hour check
(1) Replacing Engine oil and Filter
Oil filling port
Drain plug
Oil filter
Packing
Loosen
Tighten
③ Fill Engine oil
z Tighten the drain plugs. (Tightening torque :
40±5 N.m) (29.5±5 lbs-ft)
z Aid engine oil as its capacity, and check the oil
level is between MIN and MAX mark.
For oil specification, refer to “Lubricants and
Capacity” at the end of this manual.
(or See page 5-4)
z Check any leakage of the engine while running
the engine for several minutes at idle rpm.
z Stop the engine. After several minutes later,
check again the oil level is between MIN and
MAX mark.
z Install the oil gauge.
② Replace Engine oil filter
z Clean carefully around the filter.
z Coat clean engine oil on the packing of new filter
and check the packing is placed well in the groove.
z Turn the oil filter counter-clockwise to remove with
filter wrench.
z Turn the new filter clockwise to assemble until the
packing makes contact with the mounting surface.
Tighten ¾ to 1 turn more after packing contact.
z If the metal is attached to the element of oil filter to
be disassembled, contact your authorized dealer.
To Next Page
