5 -25
z The main fuse is attached to the electric wiring of
left side of the engine.
z If the main fuse is damaged, remove it from the
wiring and replace with a genuine part.
z As the main fuse is a device to protect the
electric system and wiring, check if there is
trouble in the electric system. Contact your
authorized dealer for check.
② Main fuse (SLOW BLOW FUSE) check and replacement
Main fuse
Capacity:40A
▶ If the main Fuse is cut off repeatedly, contact your authorized dealer to check the
problem.
▶ If using the alternatives instead of the rated capacity fuse, it may cause fire which
results in the damage of tractor or injury.
▶ Do not connect the electric wire to terminals of battery directly. It may cause a fire
by spark.
Notice
