Detailed Installation Instructions 2-3
Version 1.0 Copyright © 2006 by LSI Logic Corporation. All rights reserved.
LSI PCIe to SAS host adapter hardware installation is complete.
Figure 2.1 Installing an LSI PCIe to SAS x8 Host Adapter in a
PCI Express Slot
Note: The HBA shape, size, and locations of components on your
x8 (or x4) HBA and its bracket may vary from this
illustration. A PCI Express connector is smaller than a
PCI/PCI-X connector.
32-bit Slots
64-bit Slots
(3.3 V)
(3.3 V)
Edge of
Host Board
Bracket
Press Here
Press Here
HDD
Connector
Serial Signal
Cables
HBA to HDD
4 Lane Internal
HBA Connector
4 Lane
External
PCB
Receptacle
and Cable
with
Jackscrews
Screw
SFF-8484
SFF-8470
Breakout Cable
PCI Express x8 Slot
