MegaRAID SAS 9271-4i and SAS 9271-8i RAID Controllers Quick Installation Guide
June 2012
MegaRAID SAS 9271-4i and MegaRAID SAS 9271-8i RAID Controllers
4. Install the RAID controller.
Insert the controller into a PCI Express slot on the motherboard, as shown in the following figure. Press down
gently, but firmly, to seat the controller correctly in the slot. Secure the controller to the computer chassis with the
bracket screw.
J6B4 On-board Serial Universal
Asynchronous Receiver/Transmitter
(UART) connector
4-pin connector
Reserved for LSI use.
J6B5 Global drive fault LED indicator 2-pin header
Connects to a single LED that indicates drive activity on either port.
J6B6 On-board Serial UART connector 4-pin connector
Reserved for LSI use.
NOTE This controller is a PCI Express x8 card, and it can operate in x8 or x16 slots. However, some PCI
Express slots support only PCI Express graphics cards. If a RAID controller is installed, the controller does
not function.
NOTE Refer to the guide for your motherboard for information about the PCI Express slot.
Table 1 Jumpers and Connectors (Continued)
Jumper/
Connector
Type Description

LSI MegaRAID SAS 9271-4i Specifications

General

Brand	LSI
Model	MegaRAID SAS 9271-4i
Category	Controller
Language	English
