4. Basic configuration
4.2 Recommended MCCB, Earth Leakage Circuit Breaker (ELB) and
Magnetic Contactor Specification
Model MCCB ELB
Magnetic
Contactor
004iC5-1, 1F
ABS33c, UTE100 EBS33c
MC-6a
008iC5-1, 1F MC-9a, MC-9b
015iC5-1, 1F MC-18a, MC-18b
022iC5-1, 1F MC-22b
4.3 Recommendable AC/DC Reactor
Model AC input fuse AC reactor DC reactor
004iC5-1, 1F 10A 2.13mH, 5.7A 7.00mH, 5.4A
008iC5-1, 1F 20A 1.20mH, 10A 4.05mH, 9.2A
015iC5-1, 1F 30A 0.88mH, 14A 2.92mH, 13 A
022iC5-1, 1F 40A 0.56mH, 20A 1.98mH, 19 A
