LSIS SV008iC5-1 User Manual

7. Function List
7-16
7.4 I/O Group
LED
display
Parameter
name
Min/Max
range
Description
Factory
defaults
Adjustable
during run
Page
I 0 [Jump code] 0/63  This parameter sets the code
number to jump
1 O
I 1 [Filter time
constant for
V0 input]
0/9999  This is used to adjust the
analog voltage input signal via
keypad potentiometer.
10 O
I 2 [V0 input Min
voltage]
0/10
[V]
 Set the minimum voltage of
the V0 input.
0 O
I 3 [Frequency
corresponding
to I 2 ]
0/400
[Hz]
 Set the inverter output
minimum frequency at minimum
voltage of the V0 input.
0.0 O
I 4 [V0 input Max
voltage]
0/10
[V]
 Set the maximum voltage of
the V0 input.
10 O
I 5 [Frequency
corresponding
to I 4]
0/400
[Hz]
 Set the inverter output
maximum frequency at maximum
voltage of the V0 input.
60.0 O
I 6 [Filter time
constant for
V1 input]
0/9999  Set the input section’s internal
filter constant for V1 input.
10 O
I 7 [V1 input Min
voltage]
0/10
[V]
 Set the minimum voltage of
the V1 input.
0 O
I 8 [Frequency
corresponding
to I 7]
0/400
[Hz]
 Set the inverter output
minimum frequency at minimum
voltage of the V1 input.
0.0 O
I 9 [V1 input max
voltage]
0/10
[V]
 Set the maximum voltage of
the V1 input.
10 O
I10 [Frequency
corresponding
to I 9]
0/400
[Hz]
 Set the inverter output
maximum frequency at maximum
voltage of the V1 input.
60.0 O
I11 [Filter time
constant for I
input]
0/9999  Set the input section’s internal
filter constant for I input.
10 O
I12 [I input
minimum
current]
0/20
[mA]
 Set the Minimum Current of I
input.
4 O
