LSIS SV008iC5-1 User Manual

7. Function List
7-2
LED
display
Parameter
name
Min/Max
range
Description
Factory
defaults
Adjustable
during run
Page
5
Setting via
potentiometer
on the keypad
+ I terminal
6
Setting via V1
+ I terminal
7
Setting via
potentiometer
on the keypad
+ V1 terminal
8
Modbus-RTU
Communication
St1 [Multi-Step
frequency
1]
0/400
[Hz]
 This parameter sets Multi-
Step frequency 1 during
Multi-step operation.
10.0 O
St2 [Multi-Step
frequency
2]
 This parameter sets Multi-
Step frequency 2 during
Multi-step operation.
20.0 O
St3 [Multi-Step
frequency
3]
 This parameter sets Multi-
Step frequency 3 during
Multi-step operation.
30.0 O
CUr [Output
current] -
 This parameter displays
the output current to the
motor.
- -
rPM [Motor
RPM]
-
 This parameter displays
the number of Motor RPM.
- -
dCL [Inverter
DC link
voltage]
-
 This parameter displays
DC link voltage inside the
inverter.
- -
vOL [User
display
select]
-
 This parameter displays
the item selected at H73-
[Monitoring item select].
vOL
-
vOL
Output voltage
POr
Output power
tOr Torque
nOn [Fault
Display]
-
 This parameter displays
the types of faults, frequency
and operating status at the
time of the fault
- -
drC [Direction
of motor
rotation
select]
F/r  This parameter sets the
direction of motor rotation
when drv - [Drive mode] is
set to either 0 or 1.
F O
F
Forward
r
Reverse
