1. Basic System Configuration
17
No.
Name
Description
3
Panel fixed part
XGT Panel is fixed at panel by bracket.
4
Power terminal
cover
Prevention from electric shock
5
USB interface
1) USB memory connection: logging/recipe/screen data backup
2) USB memory connection: project data transmission/backup
3) User interface connection: use of mouse/keyboard
4) Printer connection: printing is available
6
Communication
interface
RS-232C, RS-422/485: For communication with controller (PLC)
7
Reset switch
Hardware reset switch
8
Battery cover
Open or close when replacing the battery
9
Tool interface
RS-232C interface
1) Project data transmission
2) Logging/recipe/alarm/screen data backup
3) Machine software upgrade
10
DIP Switches
Module setting switch
No.1
Reserved
No.2
A setting
Normal operation (default)
B setting
When upgrading Windows CE
No.3
A setting
Watchdog On (default)
B setting
Watchdog Off
No.4
A setting
RS-422/485 Terminal Switch On (120Ω)
B setting
RS-422/485 Terminal Switch Off (120Ω)
11
Power terminal
It consists of power input and FG terminal
12
Ethernet terminal
Ethernet: 10Base-T / 100Base-TX
1) Project data transmission
2) logging/recipe/alarm/screen data backup
3) machine software upgrade
4) PLC/control machine communication
※ Supported on XP40-TTA
