4. Error Code List
40
4
Error Code List
4.1 Error Message during Execution of Program
In case that problems occur during execution of XGT Panel including the start of device, diagnosis of device and
environment setting, project download, monitoring of control device, and error messages occur as type of box. At this
time the message indicates the code made by 4 digit number. The front 2 number indicate code of object and work,
the rear 2 number is message number. In case that the present error message is indicated as [0101], an error
message occurs when doing diagnosis about the status of NVRAM. When an error message occurs, refer to the
row’s number and sequence and find the category of reason and measure.
Object
Error code
Occurrence
location
Error message
Reason and measure
Type
Address
Device
diagnosis
0x01
0x01
XGT Panel
NVRAM Data
Access… FAILED!
Failed to check whether backup memory
is normal or not. If this symptom is
repeated, contact the near Customer
Service Center.
0x02
XGT Panel
BATTERY
STATUS…NOT
GOOD!
Backup data is not valid. If this symptom
is repeated when turning power off and
on, remove XGT Panel’s power and
exchange the battery.
0x03
XGT Panel
Write Operation
FAILURE!
The built-in Flash disk has an error.
Contact the near Customer Service
Center.
0x04
XGT Panel
Read Disk
Information Error!
The built-in Flash disk has an error.
Contact the near Customer Service
Center.
0x05
XGT Panel
Write Operation
FAILURE!
Check that CF card is empty, and equip
CF card and test again. If same
symptom is repeated, CF card or CF
card slot of XGT Panel may have a
problem.
0x06
XGT Panel
Read Disk
Information Error!
Check that CF card is empty, and equip
CF card and test again. If same
symptom is repeated, CF card or CF
card slot of XGT Panel may have a
problem.
Device setting
0x02
0x01
XGT Panel
Invalid timeout
value.
You inputted the wrong time which is not
within backlight setting time range. Input
the effective time.
Device
setting
0x02
0x02
XGT Panel
Not found XGT
Panel configuration
file.
There is no setting information data of
XGT Panel. If this symptom is repeated
when turning power off and on, contact
the near Customer Service Center.
0x03
XGT Panel
Please enter an
integer between 0
and 255.
When setting IP, the values within 0~255
are effective. Input the value within the
above range.
Viewing
device
information
0x03
0x01
XGT Panel
No project in XGT
Panel.
Now, there is no downloaded project so
you can’t see connection information.
Download the project from XP-Builder.
XGT Panel
Update
0x04
0x01
XGT Panel
Failed to Start
Engine. Please
update engine
again.
Because of update error or Flash disk
error, program can’t be executed. If you
can update, redo the above procedure.
