LSIS XP Series Troubleshooting Manual

2
Contents
 QUICK REFERENCE TABLE 1
 INTRODUCTION 3
Manual Structure 3
 APPLICABLE PRODUCTS 4
 PRODUCTS IDENTIFICATION 5
 RELEVANT MANUALS 7
 SAFETY PRECAUTIONS 8
 REVISION HISTORY 10
1
BASIC SYSTEM CONFIGURATION 11
1.1 System Configuration 11
1.1.1 The name and function of each part 11
1.1.2 Safety information when using the product 18
2
TROUBLESHOOTING 20
2.1 System setting 20
2.1.1 Touch Calibration 20
2.1.2 Communication Setting 21
2.1.3 Other Setting 24
2.2 Diagnosis 28
2.2.1 Communication Diagnosis 28
2.2.2 Screen Diagnosis 30
2.2.3 Touch Diagnosis 30
2.2.4 Battery Diagnosis 31
2.3 Troubleshooting when fault occurs 32
2.3.1 Booting Problem 32
2.3.2 Touch Problem 36
2.3.3 Communication Problem 37
3
MAINTENANCE 38
3.1 Maintenance 38
3.2 Daily Maintenance 38
3.3 Periodical Maintenance 39
4
ERROR CODE LIST 40
4.1 Error Message during Execution of Program 40

LSIS XP Series Specifications

General

Brand	LSIS
Model	XP Series
Category	Touch Panel
Language	English
