1. Basic System Configuration
19
Removal of the battery terminal insulating strip
An insulating strip is installed on the battery terminals to prevent battery discharge. The back-up function starts once
the strip is removed.
To remove the insulating strip, pull it downwards in the direction shown below.
‘/DC’ products are rated for a DC 24 V power supply. ‘/AC’ products are rated for AC 100-240 V power
supplies.
Do not drop the device or expose it to physical impact.
Do not disassemble the device. If the device is disassembled the product warranty will be void and LSIS will
not accept responsibility for damages.
Do not allow objects, such as metal filings or cable off-cuts inside the product.
Ensure that the mounting brackets are fixed tightly if the product is used in an environment that is affected by
vibration.
