System Components
1-7
■ 206EC/400EC Modules provide the same capabilities as the 206E and
400E modules, respectively, but add support for Caller ID information on
system display phones. To get Caller ID, first you must subscribe to the
service from your local phone company (if it is available) on a per-line
basis, then connect those lines associated with Caller ID to the line jacks
on the 206EC and/or 400EC modules. Any users with system display
phones who receive calls on Caller ID lines will get Caller ID. For more
information, see ‘‘Caller ID’’.
■ 308EC Expansion Module (Release 2.0 or later) provides expanded line
and extension capability. It has jacks for three outside lines and eight
extensions. Using combinations of modules, you can have a maximum of
40 extensions with 15 lines (one ACS processor module and four 308EC
modules) or 19 lines with eight extensions (one ACS processor module and
four 400 modules). To get Caller ID, first you must subscribe to the service
from your local phone company (if it is available) on a per-line basis, then
connect those lines associated with Caller ID to the line jacks on the
206EC, 308EC, and/or 400EC modules. Any users with system display
phones who receive calls on Caller ID lines will get Caller ID. For more
information, see ‘‘Caller ID’’.
Hereafter, references to 206 modules include 206E, 206EC, and all 206 modules
used with previous releases of the PARTNER product line. Similarly, references to
400 modules include 400E, 400EC, and all 400 modules used with previous
releases of the PARTNER product line. Any 200 modules can also be used.
If you want message-waiting capability on standard phones that are equipped with
LED-compatible message-waiting lights, you must connect those phones to
extension jacks on a PARTNER ACS processor module, a 308EC module, or on
Release 3.0 (R3.0) or later 206 modules.
NOTE:
Extension numbering is done dynamically. That is, when numbering
extensions, the 200, 400, and PARTNER MAIL VS modules count as six
extensions.
Table 1-1. Summary of Module Capacities
Module Lines Extensions
308EC 3 8
200 2 0
206 2 6
400 4 0
ACS 3 8
