Using System Programming
2-21
Programming Overlays
System Programming requires a Programming Overlay placed over the dialpad of
the system display phone at extension 10 or 11. (Overlays are provided with the
system documentation. Replacements can be ordered from the Lucent
Technologies BCS Publications Center. See "Reference Materials" under "Product
Ordering Information" on page B-4.) Figure 2-3 on page 2-22 illustrates the
Programming Overlays for the PARTNER-34D and PARTNER-18D phones.
During System Programming, the normal functions of several buttons on the
display phone at extension 10 or 11 change. For example, the left
i button
becomes
s and the right i button becomes c. The
Programming Overlay identifies these buttons.
You use the following special buttons while programming:
■ N and P cycle forward and backward through the
programming procedures. You can use these buttons to select a procedure.
(If a procedure instructs you to press
N P, pressing
these buttons one after the other enables you to repeat the current
programming procedure.)
■ n and p cycle forward and backward through a procedure’s
parameters. A parameter is typically an outside line, a pool, an extension,
or a telephone list entry.
■ D and d cycle forward and backward through the valid
entries. These buttons work only for fixed data, such as a line or extension
number. They do not work for variable data such as date, time, password,
telephone numbers, or doorphone assignments.
■ r returns the current setting to the factory setting. When using Line
Assignment (#301), removes lines from an extension; when using Pool
Extension Assignment (#314), removes pools from an extension.
■ e ends an entry of variable length, such as a telephone number in an
Allowed Phone Number List.
■ s starts the System Programming process.
■ c starts the Centralized Telephone Programming process (to
customize individual telephones centrally from extension 10 or 11).
■ f when followed by 0 0, enters or exits programming mode.
■ w enters a “wildcard” (a character that matches any digit dialed) in
telephone numbers in Allowed Phone Number Lists (#407), Disallowed
Phone Number Lists (#404), and the Forced Account Code List (#409).
