Engine
7-10
944E-42
22. Remove the engine frame skirt (4) to gain access to
the hydraulic reservoir.
23. Remove the hydraulic reservoir support bracket (5).
24. Label, disconnect and cap all hydraulic hoses
attached to the hydraulic reservoir. Cap all fittings
and openings to keep dirt and debris from entering
the hydraulic system.
25. Disconnect the connector harness at the return oil
filter pressure switch (6).
26. Remove the hydraulic reservoir (7), sliding the tank
out from under the engine and away from the engine
mount frame (8).
27. Disconnect and remove the transmission hoses. Cap
all fittings and openings to keep dirt and debris from
entering the system.
28. Remove the reservoir retainer assembly (9).
29. Remove air cleaner assembly. Refer to Section
7.8.1, “Air Cleaner Assembly Removal.”
30. Install a lifting bracket to the top of the transmission
(10).
MU2081
4
MU7350
5
MU7410
6
7
8
9
MU7420
10
11
