Transmission
6-2
944E-42
6.1 TRANSMISSION ASSEMBLY
COMPONENT TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the transmission.
The following illustration identifies the components that
are referred to throughout this section.
OUTLET
(TRANSMISSION)
HOSE
OIL FILTER
INLET
(TRANSMISSION)
HOSE
DIPSTICK AND
FILL TUBE
RADIATOR/OIL
COOLER
INLET (COOLER)
HOSE
TORQUE
CONVERTER
OUTLET (COOLER)
HOSE
THERMAL
BYPASS VALVE
