Lull 944E-42 - Cylinder Torque Specifications

8-41
944E-42
Hydraulic System
8.8.3 Cylinder Torque Specifications
a. Lift/Lower Cylinder
b. Extend/Retract Cylinder
c. Tilt Cylinder
d. Sway Cylinder
e. Transfer Carriage Cylinder
f. Slave Cylinder
g. Stabilizer Cylinder
Locknut Head Counterbalance Valve Hex Plugs
2200-2600 lb-ft (2983-3525 Nm) 500-600 lb-ft (678-814 Nm) 45-50 lb-ft (61-68 Nm) 10-12 lb-ft (14-16 Nm)
Piston Set Screw Head Counterbalance Valve
330-390 lb-ft (447-529 Nm) 13-15 lb-ft (18-20 Nm) 300-400 lb-ft (407-542 Nm) 45-50 lb-ft (61-68 Nm)
Locknut Head Valve
1100-1250 lb-ft (1491-1695 Nm) 300-400 lb-ft (407-542 Nm) 30-35 lb-ft (41-47 Nm)
Head Locknut Valve Hex Plugs
300-400 lb-ft (407-542 Nm) 1840-2025 lb-ft (2495-2745 Nm) 35-40 lb-ft (47-54 Nm) 10-12 lb-ft (14-16 Nm)
Head Locknut
250-300 lb-ft (339-407 Nm) 500-550 lb-ft (678-746 Nm)
Head Locknut
250-300 lb-ft (339-407 Nm) 445-515 lb-ft (603-698 Nm)
Head Locknut Valve
300-400 lb-ft (407-542 Nm) 1840-2025 lb-ft (2495-2745 Nm) 35-40 lb-ft (47-54 Nm)
