Hydraulic System
8-42
944E-42
h. Swing Carriage Cylinder (optional)
i. Side Tilt Carriage Cylinder (optional)
Piston Set Screw Head Valves
440-500 lb-ft (597-678 Nm) 85-95 lb-ft (115-129 Nm) 250-300 lb-ft (339-407 Nm) 30-35 lb-ft (41-47 Nm)
Locknut Head Valve
550-650 lb-ft (745-881 Nm) 300-400 lb-ft (407-542 Nm) 30-35 lb-ft (41-47 Nm)
