6.6 TRANSFER CASE COMPONENT
TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section. It is necessary that
the operator/mechanic be familiar with the name and
location of the major assemblies of the transfer case.
The following illustration identifies the components that
are referred to throughout this section.
REAR AXLE
OUTPUT SHAFT
ENGINE SUPPORT
STRUCTURE
(REFERENCE)
TRANSMISSION
ASSEMBLY
TRANSFER CASE
ASSEMBLY
FRONT AXLE
OUTPUT SHAFT
