9-47
944E-42
Electrical System
2113 52 16 Amber Coolant Temperature Coolant Temperature 2 - Data Valid but Above
Normal Operational Range - Moderately Severe
Level
2114 52 0 Red Coolant Temperature Coolant Temperature 2 - Data Valid but Above
Normal Operational Range - Most Severe Level
2115 2981 3 Amber Coolant Pressure Coolant Pressure 2 Circuit - Voltage Above
Normal, or Shorted to High Source
2116 2981 4 Amber Coolant Pressure AEB15.60 Page 153 of 157 Coolant Pressure 2
Circuit - Voltage Below Normal, or Shorted to
Low Source
2117 2981 18 Amber Coolant Pressure Coolant Pressure 2 - Data Valid but Below
Normal Operational Range - Moderately Severe
Level
2182 1072 3 Amber Engine Brake Output
#1
Engine Brake Actuator Driver 1 Circuit - Voltage
Above Normal, or Shorted to High Source
2183 1072 4 Amber Engine Brake Output
#1
Engine Brake Actuator Driver 1 Circuit - Voltage
Below Normal, or Shorted to Low Source
2185 3512 3 Amber System Diagnostic
code #1
Sensor Supply Voltage #4 Circuit - Voltage
Above Normal, or Shorted to High Source
2186 3512 4 Amber System Diagnostic
code #1
Sensor Supply Voltage #4 Circuit - Voltage
Below Normal, or Shorted to Low Source
2195 703 14 Red Auxiliary Equipment
Sensor
Auxiliary Equipment Sensor Input 3 Engine
Protection Critical - Special Instructions
2215 94 18 Amber Fuel Delivery
Pressure
Fuel Pump Delivery Pressure - Data Valid but
Below Normal Operational Range - Moderately
Severe Level
2216 94 1 Amber Fuel Delivery
Pressure
Fuel Pump Delivery Pressure - Data Valid but
Above Normal Operational Range - Moderately
Severe Level
2217 630 31 Amber Calibration Memory ECM Program Memory (RAM) Corruption -
Condition Exists
2249 157 1 Amber Injector Metering
Rail 1 Pressure
Injector Metering Rail 1 Pressure - Data Valid
but Below Normal Operational Range - Most
Severe Level
2261 94 15 Maint Fuel Delivery
Pressure
Fuel Pump Delivery Pressure - Data Valid but
Above Normal Operational Range - Least
Severe Level
2262 94 17 Maint Fuel Delivery
Pressure
Fuel Pump Delivery Pressure - Data Valid but
Below Normal Operational Range - Least
Severe Level
Fault
Codes
SPN
Codes
FMI
Codes
Lamp
Color
SPN Description Cummins Description
