ISR 12-LO • IGAR 12-LO Operating Manual Introduction • 11
Sighting:
Laser targeting light (max. power level < 1 mW,
λ = 630-680 nm, CDRH class II).
(With IGAR 12-LO measurements are possible while laser targeting light is
switched on, with ISR 12-LO measuring is stopped)
CE-label:
According to EU directives about electromagnetic immunity
Note: The determination of the technical data of this pyrometer is carried out in
accordance with VDI/VDE directive IEC TS 62942-2, “Determination of the technical data
for radiation thermometers”.
The calibration / adjustment of the instruments was carried out in accordance with
VDI/VDE directive “Temperature measurement in industry, Radiation thermometry,
Calibration of radiation thermometers”, VDI/VDE 3511, Part 4.4.
For additional details on this directive, see http://info.lumasenseinc.com/calibration
or
order the directive from “Beuth Verlag GmbH” in D-10772 Berlin, Germany.
2.4 Dimensions
Pyrometer housing:
Optical heads:
Type I (small optics):
Type II (focusable optics):
Type II (fixed adjusted):
all dimensions in mm
