ISR 12-LO • IGAR 12-LO Operating Manual Reference numbers • 39
8 Reference numbers
8.1 Reference numbers instrument
Ordering note: The pyrometers ISR 12-LO and IGAR 12-LO can be configured with different
optical fiber lengths and optical heads as well as with variious optional extras. To determine the
part number and the price for the desired combination please contact LumaSense or your
LumaSense sales representative.
Scope of delivery:
Converter, optical fiber and optical head as per configuration, works certificate, PC software
InfraWin, and user manual.
Note: The connection cable is not included with the instrument and has to be ordered
separately (see section 8, Reference numbers).
Ordering details:
In order to configure your pyrometer as fast as possible, please provide the following data:
• Instrument with basic temperture range
• Desired length of optical fiber
• Desired optical head (I or II) and the desired measuring distance
• Desired add-on options (e.g. vacuum feedthrough or continuous casting system SG-LO)
8.2 Reference numbers accessories
3 820 330 Connection cable, length 5 m, straight connector
3 820 500 Connection cable, length 10 m, straight connector
3 820 510 Connection cable, length 15 m, straight connector
3 820 810 Connection cable, length 20 m, straight connector
3 820 820 Connection cable, length 25 m, straight connector
3 820 520 Connection cable, length 30 m, straight connector
3 820 740 Connection cable, length 5 m, straight connector, temperature resistant
up to 200 °C
3 852 290 Power supply NG DC for DIN rail mounting; 100 to 240 V AC ⇒ 24 V DC, 1 A
3 852 550 Power supply NG 2D for DIN rail mounting; 85 to 265 V AC ⇒ 24 V DC, 600 mA
with 2 settable limit switches
3 852 440 Protocol transducer RS485/RS232 (switch.) <-> Profbus-DP for 1 device
3 852 460 Protocol transducer RS485 <-> Profbus DP for 32 devices
3 852 620 Protocol converter UPP RS485 or RS232 <-> ProfNet, for 1 pyrometer
3 852 630 Protocol converter UPP RS485 <-> ProfNet, for max. 32 pyrometers
3 890 650 DA 4000: LED display, 2 wire power supply, with 2 limit contacts, 230 V AC
3 891 220 DA 4000: LED display, 2 wire power supply, with 2 limit contacts, 115 V AC
3 890 560 LED digital display DA 6000-N: with possibility for pyrometer parameter settings
for digital IMPAC pyrometers; RS232 interface
3 890 570 LED digital display DA 6000-N with RS485 interface
3 890 520 LED digital display DA 6000; DA 6000-N additional with 2 limit switches and
analog input and output, RS232 interface
3 890 530 LED digital display DA 6000 with RS485 interface
