ISR 12-LO • IGAR 12-LO Operating Manual Data format UPP (Universal Pyrometer Protocol) • 35
7 Data format UPP (Universal Pyrometer
Protocol)
The data exchange occurs in ASCII format with the following transmission parameters:
The data format is: 8 data bits, 1 stop bit, even parity (8,1,e).
The device responds to the entry of a command with: output (e.g. the measuring value) + CR
(Carriage Re-turn, ASCII 13), to pure entry commands with "ok" + CR.
Every command starts with the 2-digit device address AA (e.g. "00"). This is followed by 2 small
command letters (e.g. "em" for level of emissivity ), finished with CR.
This is followed, if necessary for that command, by the ASCII parameter "X". If this parameter
"X" is omitted, then the device resets with the current parameter.
A “?“ after the small command letters answers with the respective settings (only at setting
commands, not at enquiry commands).
Example: Entry: “00em“ + <CR>
The emissivity setting (ε) of the device with the address 00 is returned
Answer: “0970“ + <CR> means Emissivity = 0.97 or 97.0%
Description
Command
Parameters
Reading temperature
value:
AAms
Output: XXXXX (dec., in 1/10 °C or °F)
in the selected measuring mode
(77770 = warm-up period of sensor or sensor
heating failed
88880 = temp.-overflow,
80000 = targeting light on (only ISR 12-LO))
Reading temperature
value repeated:
AAmsXXX
XXX = 001 ... 999 (XXX = number of measuring
values)
Reading measuring
values:
AAek
Output: XXXXXYYYYY (dec., in 1/10 °C or °F)
XXXXX = mono temperature;
YYYYY = ratio temperature
(77770 = warm-up period of sensor or sensor
heating failed
88880 = temp.-overflow,
80000 = targeting light on (only type ISR 12-LO))
Reading emissivity:
AAem
Output: XXXX (dec. 0010 ... 1000 in %)
Emissivity:
AAemXX
XX = (10 ... 99%), 00 = 100% (decimal)
Emissivity:
AAemXXXX
XXXX = (0010 ... 1000% decimal)
Emissivity slope:
AAevXXXX
XXXX = 0800 ... 1200 (equivalent to 0.8 ... 1.2)
Ratio part in
metal mode:
AAmvXX
XX = 01 ... 99%
Exposure time t
90
:
AAezX
X = 0 ... 6 (decimal)
0 = intrinsic time constant of the device
1 = 0.01 s 3 = 0.25 s 5 = 3.00 s
2 = 0.05 s 4 = 1.00 s 6 = 10.00 s
