LumaSense IS 12 User Manual

IS 12 / IGA 12 Manual Controls and Installation • 20
Focusable optics IGA 12
Measuring
distance
a [mm]
Spot size M
90
[mm]
Objective
length
S [mm]
MB 10
MB 13; 14L
MB 18
MB 23
Optics
1
a = 280 mm
1.3
0.9
0.5
0.4
30
a = 400 mm
17
1.1
0.7
0.5
9
a = 520 mm
2
1.2
0.8
0.7
0
Optics
2
a = 390 mm
1.4
1
0.6
0.45
30
a = 700 mm
2.6
1.5
1
0.8
7.9
a = 1090 mm
4.1
2.4
1.6
1.3
0
Optics
3
a = 550 mm
2
1.2
0.8
0.6
30
a = 3000 mm
10.7
5.9
4.3
3.8
2.2
a = 5600 mm
20
11
8
7
0
Aperture D [mm] *
)
13.5 to 17
13.5 to 17
13.5 to 17
10 to 13
*
)
The aperture is the effective lens diameter. It is depending on the objective length. The biggest
aperture value belongs to the fully extended objective (S = 30), the smallest aperture value for
objective length S = 0. Intermediate values have to be interpolated.
Adjusting the required measuring distance
The required measuring distance must be adjusted to achieve the spot size mentioned in the
tables above. This can be done between the smallest and the biggest limit value.
Note: The measuring object has to be bigger than or at least as big as the spot size
of the pyrometer.
To release the optics, turn it counterclockwise. Then it
can be pushed or pulled to find the correct measuring
distance. To fix the optics, turn the optics clockwise.
Adjusting the measuring distance with help of
the table:
The table mentions the minimum and maximum
measuring distance for each of the three focusable
optics. This corresponds to the longest or the shortest
objective length. As an example, a further value
between max. and min. is shown. The objective length
“S” can be measured with a caliper.
release
fix
push / pull
