IS 12 / IGA 12 Manual Introduction 9
2 Introduction
2.1 Appropriate use
The IMPAC pyrometers IS 12, IS 12-S, IGA 12, and IGA 12-S are very robust, digital, and highly
accurate infrared thermometers with temperature ranges between 250 and 3500 °C for non-
contact temperature measurement on metals, ceramics, graphite etc.
For optimal match of the instrument to the application, six different fixed optics and three
different focusable optics with extremely small spot sizes are available. The pyrometer
parameters can be selected via keys and settings are indicated on the built-in LED display. In
measuring mode, the actual temperature is indicated. The pyrometers are equipped with RS232
and RS485 serial interfaces (switchable via the keys). This enables the reading of temperature as
well as reading and adjusting pyrometer parameters using the provided software InfraWin. Two
adjustable limit switches can be used to trigger a switch process, e.g. to recognize hot objects
located in the measuring beam. A thru-lens view finder or additionally a laser targeting light for
exact alignment of the pyrometer is available. The instruments IS 12-S and IGA 12-S are
equipped with an integrated scanner which moves the measuring beam adjustable up and down
up to 4°.
Typical applications: preheating, annealing, tempering, welding, forging, hardening, sintering,
melting, soldering, rolling, brazing, normalizing.
2.2 Scope of delivery
Instrument with selectable optics, PC measurement and evaluation software InfraWin, works
certificate, and operation manual.
Note: The connection cable is not included with the instrument and has to be ordered
separately (see Chapter 10, Reference numbers).
2.3 Technical data
Temperature Ranges:
IS 12; IS 12-S: IGA 12; IGA 12-S:
550 to 1400 °C (MB 14) 250 to 1000 °C (MB 10)
600 to 1600 °C (MB 16) 300 to 1300 °C (MB 13)
650 to 1800 °C (MB 18) 350 to 1800 °C (MB 18)
750 to 2500 °C (MB 25) 400 to 2300 °C (MB 23)
550 to 2000 °C (MB 20L) 250 to 1400 °C (MB 14L)
700 to 3500 °C (MB 35L)
Sub range:
Any range adjustable within the temperature range
minimum span 51 °C
Signal processing:
Photoelectric current, digitized
Spectral ranges:
IS 12; IS 12-S: 0.7 to 1.1 µm
IGA 12; IGA 12-S: 1.45 to 1.8 µm
Power supply:
24 V DC (15 to 40 V DC) or 24 V AC (12 to 30 V AC), 48 to 62Hz
Power consumption:
Max. 7 W
Analog output:
0 to 20 mA or 4 to 20 mA switchable, load 0 ... 500 Ohm
Test current output:
10 mA, fixed
