IS 12 / IGA 12 Manual Data Format UPP • 38
Description
Command
Parameters
Analog output:
AAasX
X = 0 or 1 0 = 0 - 20 mA 1 = 4 - 20 mA
Limit contact 1:
AAs1XXXX
XXXX = switch point limit contact 1
(ASCII-hex, 4 digit, full degree in °C or °F)
Limit contact 2:
AAs2XXXX
XXXX = switch point limit contact 2
(ASCII-hex, 4 digit, full degree in °C or °F)
Setting hysteresis
limit contacts:
AAhlXX
XX = 2 … 20, full degree in °C or °F
Changing °C / °F
AAfhX
Output: X = 0: display in °C; X = 1: display in °F
Interface type:
AAin
Output: X = 1 or 2; 1 = RS232, 2 = RS485
Address:
AAgaXX
XX = 00 ... 97 (00 ... 97 = regular device addresses)
99 = Global address with response
98 = Global address without response (only setting
commands!)
Baud rate:
AAbrX
X = 1...6 or 8 (decimal)
1 = 2400 Baud 4 = 19200 Baud (7 is not allowed)
2 = 4800 Baud 5 = 38400 Baud 8 = 115200 Baud
3 = 9600 Baud 6 = 57600 Baud
Wait time:
AAtwXX
XX = 00 ... 99 (decimal)
Error status:
AAfs
Output: XX; XX=00…FF (00 = no error)
(01…FF: error code for LumaSense service)
Lock keyboard:
AAlkX
X = 0 ... 3
1 = lock lk1, removal with command lk0 or power off-on
0 = removal of lock lk1
3 = continuous lock lk3, removal only with command lk2
2 = removal of lock lk3
Reading
parameters:
AApa
Output decimal 11-digit:
Digit 1 und 2 (10...99 or 00): emissivity ε
Digit 3 (0 ... 6): t
90
(exposure time)
Digit 4 (0 ... 8): t
CL
(max. storage clear mode)
Digit 5 (0 ... 1): analog output
Digit 6 und 7: (00 ...
98): temperature
Digit 8 und 9 (00 ...
97): address
Digit 10 (0 ... 6 or 8): baud rate
Digit 11 (0): always 0
Laser targeting
light:
AAlaX
X = 0 switch off laser
X = 1 switch on laser
Internal
temperature:
AAgt
Output: XXX (dec. 000 ... 098°C or 032 ... 208°F)
Max. internal
temp.:
AAtm
Output: XXX (dec. 000 ... 098°C or 032 ... 208°F)
Ref. number:
AAbn
Output: XXXXXX (hex 6-digit)
Serial number:
AAsn
Output: XXXX (hex 4-digit)
Device type:
AAna
Output: “IS 12”, “IS 12-S”, “IGA 12” or “IGA 12-S”
(16 ASCII-characters)
Device type /
software version:
AAve
Output: XXYYZZ (6-digit decimal)
XX = 07 (IS 12, IS 12-S, IGA 12, IGA 12-S)
YY = Month of software version
ZZ = Year of software version
Software version
in detail:
AAvs
tt.mm.yy XX.YY
tt = Day; mm = month; yy = year; XX.YY = software version
Note: the letter “l” means the lower case letter of “L”.
