Lumel ND20 User Manual

24
7
Output
operation
mode
Antr
nor,
AnOL,
AnOh
Operating mode of the continuous
output:
nor – normal work,
AnOL – set value AnOL,
AnOH – set value AnOH,
nor
8
Output value
at error
AnEr 0 ... 24 in mA 24
9
Number of
impulses
Io_n
1000 ...
20000
Number of impulses for 1 kWh 5000
10
Address in
MODBUS
network
Addr 1 ... 247 1
11
Transmission
mode
trYb
r8n2,
r8E1,
r8o1,
r8n1
8n2
12 Baud rate bAUd
4.8 k, 9.6
k, 19.2 k,
38.4 k
9,6 k
13
Manufacturer’s
parameters
dEf no, yES
Restoration of manufacturer’s
parameters of the group
no
6.5.3. Setting of Alarm Parameters
Select the ALr mode in options and approve the choice by the
push-button.
Item
Para-
meter
name
Desi-
gnation
Range
Notes/
des-
cription
Manufac-
turer’s
value
1
Quantity in
the alarm
output (code
acc. to the
table 6)
AL_n table 6 P
2 Alarm type AL_t
n-on,
n-oFF,
on, oFF,
H-on,
H-oFF,
A3non,
A3nof,
A3_on,
A3_of
Fig. 9 n-on
Table 5
