Selection of the monitored value:
Table 6
Item/
value
in re-
gister
4015
Di-
splay-
ed
para-
meter
Kind of quantity
Value for the percentage
conversion of alarm valu-
es and outputs (100%)
00 off lack of quantity /alarm disabled/ none
01 U_1 voltage of phase L1 Un [V] *
02 I_1 current in the phase wire L1 In [A] *
03 P_1 active power of phase L1
Un x In x cos(0°) [W] *
04 q_1 reactive power of phase L1
Un x In x sin(90°) [var] *
05 S_1 apparent power of phase L1 Un x In [VA] *
06 PF1 active power factor PF of phase L1 1
07
tg1
tgj coefficient of phase L1
1
08 U_2 voltage of phase L2 Un [V] *
09 I_2 current in the phase wire L2 In [A] *
10 P_2 active power of phase L2
Un x In x cos(0°) [W] *
11 q_2 reactive power of phase L2
Un x In x sin(90°) [var] *
12 S_2 apparent power of phase L2 Un x In [VA] *
13 PF2 active power factor PF of phase L2 1
14
tg2
tgj coefficient of phase L2
1
15 U_3 voltage of phase L3 Un [V] *
16 I_3 current in the phase wire L3 In [A] *
17 P_3 active power of phase L3
Un x In x cos(0°) [W] *
18 q_3 reactive power of phase L3
Un x In x sin(90°) [var] *
19 S_3 apparent power of phase L3 Un x In [VA] *
20 PF3 active power factor PF of phase L3 1
