Lumel ND20 User Manual

58
6290/7290 7645 R Cosinus of angle between
U1 i I1 max
√
x
√
6292/7292 7646 R Cosinus of angle between
U2 i I2 min
-
√
x x
6294/7294 7647 R Cosinus of angle between
U2 i I2 max
-
√
x x
6296/7296 7648 R Cosinus of angle between
U3 i I3 min
-
√
x x
6298/7298 7649 R Cosinus of angle between
U3 i I3 max
-
√
x x
6300/7300 7650 R Mean 3-phase cos min -
√ √
x
6302/7302 7651 R Mean 3-phase cos max -
√ √
x
6304/7304 7652 R Angle between U1 i I1 min
° √
x
√
6306/7306 7653 R Angle between U1 i I1 max
° √
x
√
6308/7308 7654 R Angle between U2 i I2 min
° √
x x
6310/7310 7655 R Angle between U2 i I2 max
° √
x x
6312/7312 7656 R Angle between U3 i I3 min
° √
x x
6314/7314 7657 R Anlgle between U3 i I3 max
° √
x x
6316/7316 7658 R Current in neutral wire min A
√
x x
6318/7318 7659 R Current in neutral wire max A
√
x x
6320/7800 7660 R U1 – harmonic 2 %
√
x
√
… … … … …
6358/7838 7679 R U1 - harmonic 21 %
√
x
√
6360/7840 7680 R U2 - harmonic 2 %
√
x x
… … … … …
6398/7878 7699 R U2 - harmonic 21 %
√
x x
6400/7880 7700 R U3 - harmonic 2 %
√
x x
… … … … …
6438/7918 7719 R U3 - harmonic 21 %
√
x x
