63
Power input:
- in supply circuit 6 VA
- in voltage circuit 0.05 VA
- in current circuit 0.05 VA
Display field: dedicated display LCD 3.5’’
Realay output: relay, voltageless NO contacts
load capacity 250 V~/ 0.5 A ~
Analog output: current 0(4) ... 20 ...24 mA
load resistance 250 W
resolution 0.01 % of the range
basic error 0.2%
Serial interface RS-485: address 1...247;
mode: 8N2,8E1, 8O1,8N1;
baud rate: 4.8, 9.6, 19.2, 38.4 kbit/s
transmission protocol: Modbus RTU
response time: 600 ms
Energy impulse output output of OC type (NPN), passive
of class A , acc.to EN 62053-31
supply voltage18 .. 27 V,
current 10 .. 27 mA
Constant of OC type
output impulse: 1000 - 20000 imp./kWh
independently of set tr_U, tr_I ratios
Protection grade ensured by the casing:
- from frontal side IP 65
- from terminal side IP 20
Weight 0.3 kg
Overall dimensions 96 x 96 x 77 mm
