Lumens VCBC106d User Manual

20
1st Level
Major Items
2nd Level
Minor Items
3rd Level
Adjustment Values
Function Descriptions
Tally Lamp
On/Off
Select to enable or disable Tally Lamp
function.
Tally CMMD Mode
Normal/ Link
Set whether the indicator is linked
with RS232 command
 Normal (Not linked): The indicator
light status and mode shall be set
separately.
 When the indicator light is on and
the default mode is off, additional
command is required to set the
indicator light mode
 Setting indicator light mode when
the indicator light is off will not
trigger the indicator light
 Link:
 When the indicator light is on, the
default mode is red light
 Setting indicator light mode when
the indicator light is off will turn on
the indicator light
Language
English / 中文
Initial Position
Last MEM / 1st Preset
Select the camera lens to return to the
last operated position or the first
preset position after POWER ON
<Remark> 1st Preset = Preset 0
Control Device
Encoder / Controller
Control Device setting,
Controller: for joystick
Encoder: for tracking system
Motionless Preset
On/Off
When the function is enabled, the
screen will Freeze when Preset is
executed. Freeze will be released
after Preset is completed.
Control Port
RS-232/RS-422
Choose whether the control interface
used is RS-232 or RS-422
Protocol
VISCA / Pelco D
Baud Rate
9600/38400
Choose the transmission speed of the
control signal
VISCA Address
0~7
The Protocol set to VISCA allows the
camera ID address to be assigned.
Select 0 for automation.
PELCO D Address
1 ~255
The Protocol set to Pelco D allows the
camera ID address to be assigned.
Output Mode
1. 3840x2160/59.94p
2. 3840x2160/50p
3. 3840x2160/29.97p
4. 3840x2160/25p
5. 1080p/59.94
6. 1080p/50
7. 1080p/29.97
8. 1080p/25
9. 720p/59.94
10. 720p/50
11. 1080i/59.94
12. 1080i/50
Choose the output resolution
Color Space
Standard Profile /
REC.709 / BT.2020
Set the standard for color gamut
Factory Reset
On/Off
Resume the factory default setting
Status
Display the current setting status
