Lumens VCBC106d User Manual

24
5.2.2 Viewing In Real Time
<Remark> Preview pane is not supported when NDI is on
No
Item
Function Descriptions
NDI ON
NDI OFF
1
Pan/Tilt setting
Adjust the Pan/Tilt position of the camera screen
V
V
2
Zoom ratio
Adjust the zoom-in or zoom-out ratio via scroll bar
V
V
3
Preview window
Display the screen currently captured by the
camera
V
4
Preset setting
Select the number first and then select SAVE or
LOAD
V
V
5
PTZ Only
Enable/disable PTZ Only
 Disable (Default): Call the preset, execute
Pan/Tilt/Zoom/Focus + picture parameters setting
 Enable: Call the preset, only execute
Pan/Tilt/Zoom/Focus
V
V
6
Switch to Full Screen
Switch the preview window to full screen
V
7
Power button
Turn on or turn off the camera power
V
V
4
3
2
1
5
6
7
