Lumex SELECT Series User Manual

LS200-INS-LAB-RevB17 10
5 SETUP
 WARNING:Alwaysuseastandardhealthcarebedframewithappropriatesafeguards
andprotocols.Frameandsiderailsmustbeproperlysizedrelativetothemattressto
helpminimizeanygapsthatmightentrapapatient’sheadorbody.
MATTRESS INSTALLATION
1. Remove existing mattress from bed frame.
2. Replace the mattress with the mattress replacement system. Orient mattress so that the air
tube is at the foot of the bed.
If re-installing the Select Mattress System onto a new frame or for a new patient, check
mattress surface for staining and soiling; clean and / or disinfect as required (see Care and
Cleaning section).
3. Level bed and lock brakes.
4. Ensure mattress is properly positioned with no gaps between mattress and bed frame or
side rails.
5. Secure straps on bottom of mattress to the bed frame.
PUMP INSTALLATION
POWER SwitchHanger
Pump Rear View Pump Front Panel
1. Place pump on a horizontal surface or hang the pump on the foot board of the bed frame
with built-in hanger on back of pump.
2. Connect pump hoses to mattress — attach the air tube connectors to the socket on the
right pump front panel. Ensure air hoses are not kinked and will not be pinched by any
articulated bed mechanisms.
3. Ensure POWER switch is in the OFF position.
4. Plug pump into a properly grounded wall outlet. Verify power to this outlet is not
controlled by a wall switch.
 WARNING:AvoidFireHazards–Tominimizeriskofre,connectthepowercorddirectly
intoawall-mountedoutlet.Donotuseextensioncordsormultipleoutletstrips.
